RiPanel Processing Center is shop floor planning and status feedback software for control and switchgear manufacturing. The RiPanel Processing Center consists of two modules: Layout Tool and Job Management.
Frequently Asked Questions (FAQ)
In Job Management, production orders can be created from projects and assigned to a resource. This produces the following benefits:
- Digital overview for the job management of individual production steps
- Resource utilization overview
- Improved transparency and overview
- Shorter setup times by combining identical parts via drag-and-drop.
▪ Assignment of production documents to production orders
▪ Consistent solution for production with an interface to Eplan Engineering
- Improved collaboration (human/machine, between work steps, and between engineering and production)
▪ Simple, fast change management
- Central communication of changes, central transfer of new project data, central control of new schedules (incl. machine programs)
Project data for machining can be created in Layout module. Layout consists of two modules: The Project module and the Library module. Customer projects with machining are created from the master data in the Project module.
In the Project module, it is possible to import CAD data in DXF format after creating a new project.
The master data is managed in the library. In addition to Rittal enclosures and accessories, user-defined articles and components can be created and classified in the library.
Rittal Perforex MT (from year of construction 2021)
Rittal Secarex AC 18 from HMI version 2.8.0.10 or higher
The RiPanel Processing Center is a future-oriented cloud technology. An Internet connection is required for the RiPanel Processing Center and the Rittal Perforex MT.
The latest versions of Microsoft Edge, Mozilla Firefox and Google Chrome are supported.
No, all orders sent to the machine are still pending at the machine.
Eplan Pro Panel 2.9 Service Pack I Update 7 or higher
Eplan Pro Panel 2022 or higher
The RiPanel Processing Center manual is available in the header bar under the "?" help icon.
